small outdoor advertising led display - Product
Place of Origin : Shenzhen,China
Delivery Time : 7-25 Working Days After Receipt Your Deposit
Product Description
Specificationssmall outdoor advertising led display
1.high brightness
2.waterproof
3.easy installation
4.CE,ROHS,FCC
- - - -
No. | Specifications | |
1. | Part No. | P16small outdoor advertising led display |
2. | LED chip | Taiwan/Silan/Cree/Cree Cotco |
3. | Physical Pixel Pitch | 16mm |
4. | Physical Pixel Density | 3906dots/m2 |
5. | Pixel composition | 2Red, 1Green,1Blue |
6. | Moduel Size | 256*128mm |
7. | Moduel resolution | 16*8dots |
8. | Cabinet thickness | < 170 m
Physical Specification
Other Specification : Specificationssmall Outdoor Advertising Led Display
1.high Brightness
2.waterproof
3.easy Installation
4.CE,ROHS,FCC
- - - -
No. | Specifications | |
1. | Part No. | P16small Outdoor Advertising Led Display |
2. | LED Chip | Taiwan/Silan/Cree/Cree Cotco |
3. | Physical Pixel Pitch | 16mm |
4. | Physical Pixel Density | 3906dots/m2 |
5. | Pixel Composition | 2Red, 1Green,1Blue |
6. | Moduel Size | 256*128mm |
7. | Moduel Resolution | 16*8dots |
8. | Cabinet Thickness | < 170 Mm |
9. | Bracket Of Cabinet | Easy To Install Onto The LED Cabinet And Unistall . |
10. | Brightness | >6500 Nits |
11. | Colors | 16.7million |
12. | Viewing Angle | Horizontal 120, Vertical : 60 |
13. | Viewing Distance | 15m -200m |
14. | Soft Rubber Mask | To Protect Player And LED Display Itself . |
15. | Scan Frequency | 600 HzThere Will Be One Receive Card In Each Cabinet ,so That The LED Display Won't Sparked .Also It Is Very Easy To Move And Connetct |
16. | Video Frame Rate | >150 Fps |
17. | Color Temperature | 6500K To 9500K Adjustable |
18. | Control Method | Controlled By PC, Synchronous Display |
19. | Life Span( Half Brightness) | >100,000 Hours |
20. | Weight | 70Kg /sqm |
21. | IP Rate | IP65 ( Front Side And Rear Side) |
22. | Average Power Consumption | 400W/sqm |
23. | Peak Power Consumption | 800W/sqm |
24. | Input Voltage | AC220V/50Hz 10% Or AC110V/60Hz 10% Or AC380V/60Hz 10% |
25. | Operating Environment | Temperature:-20+60 Humidity:10%95%RH |
26. | Operating System | Windows 98/2000/ME/XP |
27. | Type Of Video Signal | S-video, Composite Video ,RGB ,VGA ,DVI |
- - - -
