Mig350 New (Igbt) - Product

Other Specification : Model Unit MIG 350 (IGBT) Input Power Voltage V AC380 ± 15% Rated Input Power Capacity KVA 15KVA Frequency Hz 50/60 No-load Voltage V 60V MIG Output Current A 60-350 MMA Output Current A 20-350 Rated Output Voltage V 15-36V Duty Cycle % 60 No-load Loss W 80 Efficiency % 85 Power Factor(Cos Φ ) 0.93 Insulation Class F Net Weight Kg 29 Unit Size Mm 570*285*470 Diameter Of Wire Mm 0.8/1.0/1.2 Thrust Current A 0-110 Diameter Of Rod Mm 1.6-6 Connector PCS 3PCS KDP70
