Otdr Tester for Sale-AOR500 - [ Buy Product ]

Place of Origin : Shenzhen,China
Post Date : 17-04-2023
Expiry Date : 27-07-2026

Trade Description

The Main Features Of Otdr For Sale Are: Convenient One-button Testing. High-speed Signal Processing, Less Test Time, And Fast Analysis. Color TFT LCD. USB Port Connects To PC. Input Optical Signal Auto-detection And Self-protection. Built-in VFL.

Specification Of Fiber Optic Otdr Tester For Sale-AOR500
AOR500-S AOR500-A AOR500-B
Wavelength 1310±20nm / 1550±20nm
Dynamic Range 24/22dB 28dB / 26dB 32dB / 30dB
Event Dead Zone < 1.5m
Attenuation Dead Zone < 8.0m
Pulse Width 10ns, 25ns, 50ns, 100ns, 250ns, 500ns, 1000ns,2500ns,5000ns, 10000ns
Distance Uncertainty ±(1.0m ± 0.005% * Testing Distance ± Resolution)
Linearity ±0.05dB/ DB
Loss Resolution 0.001dB
Distance Resolution 1m
Connector FC (optional: SC, ST, LC)
VFL 1mW
Data Storage > 10000 Traces (standard 1GB SD Card)
Display 3.5 Inch TFT Color LCD
Interface USB
Battery Built-in Rechargeable Battery
Working Time >10 Hrs (Bellcore TR-NWT-001138)
Operating Temp -10 -- +50 ?, < 90%RH
Storage Temp -20 -- +60 ?, < 90%RH
Net Weight 0.9 Kg
Dimension 230mm×120mm×60mm

There Are Many Fiber Optic Accessories Suppliers, But We Are One Of The Best Choices For You.
