Satellite finder - Product

Place of Origin : Tian Jin,China

Product Description

Feature:
1. Satellite finder of king around the world
2. NIT function
3. Constellation diagram function
4. Display:3.5 inch high quality TFT LCD TV
5. Audio output:Built in speaker with volume control
6. New FAST Spectrum Analyzer
7. DiseqC switch 8 ways
8. Motor control diseqc 1.0/1.2/usals
9. Unicable standard-1.2.3.4 SCR0,1,2,3
10. All LNB types supported
11. Very sensitive new tuner
12. Calibrated meter to industry standards
...

Physical Specification

Other Specification : Technical Data: 1.Frequency Range: 950MHz~2150MHz 2.Signal Level Range: -65dBm~-25dBm 3.Symbol Rate:2Msps~45Msps 4.RF Input Connector: F Type 5.Input Resistance: 75ohm 6.22KHz Signal: 22KHzÂ±2KHz 7.Support DiseqC 8.Items Of Measurement :QPSK Signal Level, Bit Error Rate, Carrier Rate 9.Storage: 40 Value Of Measurement, 80 Configuration Data,10 Spectrum Data 10.Support Constellation Diagram 11.Mode Of Satellite Finding: Sound And Colour 3.5〞TFT 12.Displayed Information:Satelliteâ€™s Azimuth,Elevation,Polarization 13.LNB Power Supply: Horizontal Polarization:+18V,≦400mA Vertical Polarization:+13V, ≦400mA 14.Total Power: 8W 15.Working Time: 3~4hours 16.Connector: Rs232 Or USB(Optical) 17.Working Temperature: 0~40℃ 18.Storage Temperature: -20~70℃
