STX-4001 diamond wire saw machine is designed for cutting samples of different rigidity such as ceramics, crystals, glass, metals, rocks, thermoelectric materials, infrared optical materials, composite materials, and biomedical materials, etc.diamond wire saw machine is mainly used to machine larger size materials and the cutting size is up to 1m.
|
Major Parameters of Multi Wire Diamond Saw |
1. Speed Of The Cutting Wire: Adjustable Within The Range Of 0 ~ 5m/s. 2. Total Length Of Cutting Wire: ≤400m. 3. Diameter Of Cutting Wire: ≤0.65mm. 4. Z-axis Travel Distance: ≤1m. 5. Cutting Speed: 0.05~100mm/min. 6. Y-axis Travel Distance: ≤1m. 7. Y-axis Feed Mode: Manual. 8. Tensioning Mode: Pneumatic Tensioning. 9. Workbench Size Of High Performance Diamond Wire Saw: 1.2(L)×1m(W). 10. Diameter And Length Of Workpiece: Φ1×1m (max). 11. Power Supply: 220V/50Hz. 12.Safety Control Device, Automatic Shutdown When Wire Is Broken, High Performance Diamond Wire Saw Has Corner Cutting Protection. 13. Main Motor Type OfLaboratory Diamond Wire Saw: Servo Motor. 14. Control Mode: PLC, Touch Screen. 15. Display Mode: Digital Display. 16. Workbench Load: 1.5t (max). 17. Power Of The Whole Machine: 2.5kW. |
|
|
|
18.Specifications Of Continuous Diamond Wire Saw: ·Outline Dimension: 2850(L)×1850(W)×3350mm(H). ·Net Weight: ≈2.5t |
|
