Digital Micro Vicker Hardness Tester SMV-2000MZ - Product
Place of Origin : Guiyang,China
Product Description
Micro Vickers Hardness Tester made with a unique and precision design in the field of mechanics ,optics and light source,and firstly adopted cold light source is able to produce a clearer indentation and hence a more precise measurement. By means of a 20 xlens and a 40 xlens the tester has a wider measurement field and a broader usage range. Equipped with a large LCD screen.The operation is more directly and clearly.
Physical Specification
Other Specification : Model
SMV-1000M/2000M
SMV-1000MZ/2000MZ
Testing Force
0.098N, 0.246N, 0.49N, 0.98N, 1.96N, 2.94N, 4.90N, 9.80N
10gf, 25gf, 50gf, 100gf, 200gf, 300gf, 500gf, 1000gf
Magnification Of Microscope
100X 400X
Testing Range
1HV～2967HV
Loading Control
Automatic(loading, Dwell, Unloading)
Turret
Manual
Automatic ( Auto-Turret)
Objective/Indenters Switch
Manual
Automatic ( Auto-Turret)
Hardness Indication
LCD Display
Dwell Time
5～60s
Printer
Built-in Mini-printer
Dimension Of The XY Stage
100 Ã 100 Mm
Travel Of The XY Stage
25 Ã 25mm
Max Of Height Of Specimen
70mm
Instrument Throat
95mm
Accuracy
Standard Conforms To EN-ISO 6507
Power Supply
AC220V/50Hz; 110V/60Hz
Instrument Dimension
530x450x750mm 35 KGS
Standard Delivery
Vickers Indenter; Standard Blocks; Objectives 10X, 40X; 10X Digital Eyepiece;
Level; XY Table, Thin Specimen Testing Table, Fork-shaped Anvil, Fine Wire Test Table , Build-in Mini Printer; Power Cable, Assistant Tools, RS232 Cable.
Optional Accessories:
CCD Adapter, CCD, PC, Micro Hardness Testing Software
Auto-turret(SMV-1000M Need) , Knoop Indenter
8†LCD Screen
