Place of Origin : Zhejiang,China
Delivery Terms : 7-15days
Delivery Time : 7-15days
Product Capacity : 1000
Payment Terms : 1-3 Days
Accuracy: ±1%
Nominal diameter range: DN15…6000 / ½…240?
Max temperature: up to +160°C / +320°F;
Output: 4~20mA, Relay, RS485
Digtal communication: RS485 Modbus, HART
Clamp-on Ultrasonic Flowmeter Principle Is The Use Of Ultrasonic Sensors Send Out Ultrasonic Signals, Propagation In The Fluid And Bounce Back, And Then By The Sensor To Receive, Analyze, So As To Deduce The Fluid Flow Rate And Flow. This Kind Of Flowmeter Will Not Touch The Fluid, So It Will Not Affect The Fluidity, And Has A Wide Range Of Measurement, Accuracy And Other Advantages.
Clamp-on Ultrasonic Flowmeter Can Realize DN15~DN6000 Pipeline Flow Measurement. Different Sensors Are Suitable For Different Caliber Ranges And Different Temperature Ranges, With A Wide Range Of Applications. No Need To Break The Pipe, Easy To Measure. No Need To Open The Pipe Sensor Attached To The Pipe To Measure The Flow. Installation Is Very Convenient And Quick.
Non-contact Measurement Method, There Is No Need To Destroy The Pipeline During The Measurement Process, No Need To Stop Production, The Clamp On Flow Meter Does Not Contact The Measured Medium, And There Is No Pressure Loss.
Broad Pipe Size Compatibility:Suitable For Pipes Ranging From Small To Large Diameters,typically From DN15 To DN6000,and Compatible With Various Pipe Materials. This Clamp-on Design Offers Significant Cost Savings,particularly For Large-diameter Pipes.
Versatile Liquid Measurement:Capable Of Measuring Both Conductive And Non-conductive Liquids,making It Suitable For Water,oil,chemical Liquids,and More
Measurement Range: The Measurable Flow Rate Range Of The External Clip-on Is 0~10m/s.
8-36VDC, AC85-264V Power Supply Modes Are Optional;
Protection Grade: IP68
Process Temperature: A) Standard Clamp-on Sensor: -30?~90?;
b) High-temperature Clamp-on Sensor: -30?~160?;
c) Plug-in Sensor: -30?~160?;
d) Pipe Segment Sensor: -30?~160?.
Applicable Pipes: Ultrasonic Flow Meters Are Suitable For Various Lined Or Unlined Metal And Plastic Tight Pipes. Such As Steel, Stainless Steel, Cast Iron, Cement Pipe, Copper, PVC, Aluminum, Fiberglass, Etc.
