Place of Origin : Huizhou,China
Post Date : 21-03-2024
Expiry Date : 13-07-2028

Smart Lithium Backup Power Use Of Lithium Iron Phosphate Cell, Safe And Reliable, Support For Old And New Batteries, Lithium Phosphate Prismatic Battery Mixed Use, Significantly Reduce Operating Costs.

Specification Of Intelligent Lithium Battery
Item Parameter Note
Model 48V 100Ah
Pack Method 15S 1P
Rated Voltage 48V
Rated Capacity ±5% 100Ah
Rated Energy ±5% 4.8kWh
Input Voltage 43.2V DC~58V DC Any Value Within The Voltage Range Is
Normal Charging
Output Voltage 48V DC~57V DC Constant Voltage Discharge, The Default Is
-57V DC
Maximum Charging Power 4800W
Maximum Charging Current 100A
Maximum Discharge Power 4800W
Maximum Discharge Current 100A
Constant Voltage Discharge Regulation
Accuracy ±0.6%
Comm Port CAN/RS485
Interface Parameters Power Terminal: 2 M6 OT Terminals
Monitoring Interface: 1 RS485, 2 RJ45
Maximum Number Of Parallel Groups 30 Groups
Atmospheric Pressure 70kPa~106kPa
Cooling Way Natural Cooling
Anti-theft Function Software Anti-theft Function, Gyroscope Movement Monitoring, Etc.
Alerts And Protection Capabilities Over Temperature, Low Temperature, Over Current, Short Circuit, Over Charge, Over Discharge, Etc.
Battery Pack Size 441*399*129mm
Battery Box Sheet Metal
Battery Pack Weight ˜42kg

Operation Interface Of Intelligent Li Ion Battery
Feacture Of Intelligent Lithium Phosphate Solar Battery
Parallel Power Expansion Characteristics: N Groups Of Parallel Connections Support Maximum Power P=24kW. Please Refer To The Parallel Application For Specific Calculations.
